Sino Hydraulic SG04 Series Hydraulic Pump Parts

Quantity:

Contact Now

add to cart

SG04

Toshiba SG04 is a hydraulic Motor spare part for Toshiba.

Toshiba SG04 Spare Parts

The Toshiba SG04 series hydraulic rotary motors (often paired with MFB80 / MFC80 / SG04E) are widely used in the rotating mechanisms of various 10 to 15 tonne small and medium-sized excavators (such as Sumitomo SH120, Katsura HD450, Yuchai YC135, Caterpillar E120B, etc.). The core wear parts of this model are mainly composed of rotary overhaul components (Rotary Group) and brake friction plates, and there are mature replacement spare parts and repair packages available for after-sales service.More models are waiting for you to choose, you are welcome to contact customer service：

Model/规格型号	存货名称	Product name	Model used/适用机型
Toshiba SG04 Hydraulic Motor Parts	缸体	CYLINDER BLOCK	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	缸体 E311C 长齿	CYLINDER BLOCK	SG04,MFB80,MFC80,E311HM,E312CHM,MFC90,
Toshiba SG04 Hydraulic Motor Parts	配油盘	VALVE PLATE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	柱塞	PISTON SHOE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM，PVA82L1,
Toshiba SG04 Hydraulic Motor Parts	回程盘 OLD	SET PLATE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	回程盘 NEW SH260HM	SET PLATE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	介子(回程盘)	BUSH OF SET PLATE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	止推板	SHOE PLATE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	轴封挡圈	Shaft seal retaining ring	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	铁圈	SIDERSPHERE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	白胶圏	RUBBER RING	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	碟形弹簧	DISC SPRING	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	轴承 NK304020	BEARING	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	轴承 32207（4T）	BEARING	SG04,MFB80,MFC80,PSV2-55T,PSV2-52,SH100A/A2,SH120A1,SH120A2,SH135,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM,SK200-6EXM,DH258XM,M4V147,
Toshiba SG04 Hydraulic Motor Parts	摩擦片	FRICTION PLATE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	分隔片	SEPARATION PLATE	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	刹车弹簧	SPRING	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	刹车盘	BRAKE PISTON	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM
Toshiba SG04 Hydraulic Motor Parts	修理包	SEAL KIT	SG04,MFB80,MFC80,E110BHM,E120BHM,E312HM,E312CHM,E312BHM,E311HM,SK100-1HM,SK120-1HM,SK100-2HM,SK120-2HM,SK100-3HM,SK120-3HM,HD250-7HM,HD400-7HM,HD450-7HM,HD512HM,HD510HM,YC135HM

**"Hydraulic Components: The Powerhouse of Precision and Performance"**

When it comes to reliability, efficiency, and unmatched durability, hydraulic components stand as the backbone of modern industrial and mechanical systems. Engineered to deliver exceptional force transmission with minimal energy loss, these components—including pumps, valves, cylinders, and motors—are designed to withstand extreme pressures and demanding environments.
